Frame Timing

The Frame-timing dialogue is a diagnostic tool used to inspect temporal structure and continuity at the frame level within a decode-orc pipeline. Like Preview and Frame-scope, it is not a pipeline stage, but a read-only analysis view that attaches to preview-capable stages.

The Frame-timing dialogue focuses on when frames occur and how they relate to one another, rather than how they look. It is primarily concerned with cadence, continuity, colour-frame sequence, and metadata hints that describe timing.

Renamed in v2.0: This dialogue was called the Field-timing dialogue in Decode-Orc 1.x.

Purpose and use cases

The Frame-timing dialogue is used to:

  • Verify colour-frame index continuity (PAL 4-frame cycle, NTSC A/B 2-frame cycle)
  • Inspect dropped, duplicated, or skipped frames
  • Validate alignment between multiple sources
  • Diagnose cadence issues (e.g. irregular frame progression)
  • Confirm correct behaviour of frame re-mapping and alignment stages

It is especially useful when working with:

  • Multiple captures of the same material
  • Pipelines using frame_map and/or source_align
  • Stack-based workflows
  • Sources with known timing instability or capture errors

Attaching the Frame-timing dialogue

The Frame-timing dialogue attaches to the currently previewed stage and analyses the post-stage output stream.

All timing information shown reflects:

  • Upstream transforms
  • Frame reordering
  • Alignment offsets
  • Phase correction

Core concepts

Frame ID

Each output frame is identified by a FrameID. Internally (and in the project file) frames are numbered from 0; the dialogue presents frame numbers 1-based, matching the preview window.

If frames are reordered or dropped upstream, the frame numbers shown here reflect the effective output ordering, not the original capture numbering.

Colour-frame index

Each frame carries a colour-frame index from the FrameDescriptor:

  • PAL / PAL-M: position within the 4-frame colour sequence (1, 2, 3, or 4 per EBU Tech. 3280-E §1.1.1 / ITU-R BT.1700-1 Annex 1 Part B).
  • NTSC: A (0) or B (1) per SMPTE 244M-2003 §3.2.
  • Unknown / undetectable: −1 (shown as "–" in the display).

The dialogue visualises the colour-frame index progression across time, making it easy to spot:

  • Phase breaks introduced by capture errors or player skips
  • Incorrect sequence after re-mapping

Frame continuity

The dialogue tracks continuity of frames over time, highlighting:

  • Missing frames
  • Duplicated frames (before frame_map duplicate removal)
  • Unexpected jumps in source frame references
  • Padding frames (is_padding_frame = true) inserted by frame_map

This is critical for diagnosing issues introduced by capture errors or incorrect range mapping.

Field line counts

For each frame the dialogue shows the line count of each field block (field 1 and field 2), making non-standard frame geometry visible at a glance.

Interaction with transform stages

The Frame-timing dialogue reflects the effects of timing-related transform stages directly.

Frame Map

After frame_map, the dialogue shows:

  • Reordered frame IDs
  • Gaps where ranges were omitted
  • Padding frames inserted to fill detected sequence gaps
  • Frames removed by duplicate detection

This allows immediate verification that range specifications behave as intended.

Source Align

After source_align, the dialogue shows:

  • Aligned starting points across sources
  • Dropped leading frames
  • Colour-frame index consistency across aligned outputs

This is the primary tool for confirming that multiple inputs are correctly synchronised before stacking.

Stacker

After stacker, the dialogue shows:

  • A single, unified frame timeline
  • Stable colour-frame index progression (assuming aligned inputs)
  • Absence of per-source discontinuities

It is useful for confirming that stacking did not introduce timing artefacts.

Typical workflows

Common uses of the Frame-timing dialogue include:

  • Verifying colour-frame sequence immediately after a source stage
  • Confirming correct behaviour of frame_map range specifications
  • Validating multi-source alignment before stacking
  • Diagnosing phase-sequence issues observed in preview output
  • Comparing timing behaviour before and after transform changes

Limitations

  • The Frame-timing dialogue is read-only and non-destructive.
  • It does not display sample-level or image-level data.
  • Interpretation assumes that upstream metadata (VBI, timecode, colour burst) is present and valid.

Notes on Frame-timing analysis

  • The dialogue always reflects the current preview stage output.
  • Timing anomalies shown here often explain visual artefacts seen in Preview.
  • For best results, use the Frame-timing dialogue together with Preview and Frame-scope.

The Frame-timing dialogue provides essential visibility into the temporal correctness of decode-orc pipelines, complementing visual and waveform-based inspection tools.
